The window comparator signal will be output when the analog input O/OI value is between the upper
and lower limit settings. It is useful for monitoring the analog input at a level to detect disconnection or
other faults.
The hysteresis width can be set for the upper and lower limit level settings for the window comparator
function.
In addition to the hysteresis width, the upper and lower limit levels can be set individually for each of the
analog input signals O and OI.
The analog operation level during WCO/WCOI output can be set to a fixed value. To do so, set the
Analog Operation Level at O/OI/FE Disconnection (b070/b071). When set to no, the analog input value
will be used “as is.”
The signals ODc and OIDc will be output in the same way as WCO and WCOI, respectively.
Window Comparator O
Upper Limit Level
Lower limit level + Hysteresis width 2
(0. min.) to 100.
Set an upper limit level.
Window Comparator OI Upper
Limit Level
Window Comparator O
Lower Limit Level
0. to Lower limit level − Hysteresis width
2 (100. max.)
Set a lower limit level.
Window Comparator OI Lower
Limit Level
0. to (Upper limit level − Lower limit level)
2 (10. max.)
Set a hysteresis width for the upper and
Window Comparator OI Hys-
Analog Operation Level at O
Disconnection
0. to 100.
255: no (Disabled)
Set the analog operation level during
WCO/WCOI (ODc/OIDc) output.
Analog Operation Level at OI
Disconnection
Multi-function Output 11/12
27: ODc (Analog O disconnection
detection)
28: OIDc (Analog OI
disconnection detection)
54: WCO
(Window Comparator O)
55: WCOI
(Window Comparator OI)
Selection
Multi-function Relay Output
(AL1, AL2) Function Selection
Note Set the upper and lower limit level settings for the window comparator function as a percentage [%] of the
input voltage (10 V) or current (20 mA).
7-8-20 Window Comparator (WCO/WCFI) (Disconnection Detection
ODc/FIDc)
