6-8-2 Functional Limitations in PM Motor Mode
In the PM motor mode, induction motor-related functions and some other functions cannot be used.
Parameters for these unavailable functions are not displayed in the PM mode.
In addition, for some parameters, the default data are changed for use with the PM motor.
This section lists the unavailable parameters, unavailable selection functions, and parameter with
changed default data, in this order.
The following parameters are not available and therefore not displayed on the Digital Operator.
Parameter
No.
Function name
d008
Real Frequency Monitor
d009
Torque Reference Monitor
d010
Torque Bias Monitor
d012
Output Torque Monitor
d029
Position Command Monitor
d030
Current Position Monitor
A038,
A039
Jogging function
A041 to
A043
Torque boost function
A044
1st Control Method
A045
1st Output Voltage Gain
A046
1st Automatic Torque Boost Voltage
Compensation Gain
A047
1st Automatic Torque Boost Slip Com-
pensation Gain
A081
AVR function
A083
AVR Filter Time Constant
A084
AVR Gain at Deceleration
A085
Operation Mode Selection
A086
Energy-saving Response/Accuracy
Adjustment
b027
Overcurrent Suppression Selection
b028 to
b030
Frequency pull-in restart function
b036
Reduced Voltage Startup Selection
b040 to
b044
Torque limit function
b045
Torque LADSTOP Selection
b046
Reverse Rotation Prevention Selection
b049
Heavy load/Light Load Selection
Parameter
No.
Function name
b100 to
b113
Free V/f function
b120 to
b127
Brake control function
C054 to
C059
Overtorque/Undertorque function
H002 to
H034
Induction motor parameter
H050
V/f Control With Speed Feedback Slip
Compensation Proportional Gain
H051
V/f Control With Speed Feedback Slip
Compensation Integral Gain
P004
Pulse Train Input Type Selection
P011
Number of Encoder Pulses
P012
Simple Position Control Selection
P014
Creep Speed Moving Amount
P015
Creep Speed Setting
P017
Positioning Completion Range Setting
P026
Overspeed Error Detection Level
P027
Speed Deviation Excessive Level
P033 to
P041
Torque control function
P060 to
P083
Simple position control
F202 to
F203
A201 to
A296
b213 to
b223
C241
H202 to
H234
2nd control function
Unavailable Parameters
