4 Parameter List
4 - 7
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
4-3-1 Group A: Standard Function Parameters
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
Basic operation
settings
A001
1st Frequency Refer-
ence Selection
00:
Digital Operator (Volume)
*1
01: Control circuit terminal block (Ana-
log input)
02: Digital Operator (F001)
03: Modbus communication
04: Option
06: Pulse train frequency
07: DriveProgramming
10: Operation function output
02
Disabled
−
P. 5-23
A201
2nd Frequency Refer-
ence Selection
02
Disabled
A002
1st RUN Command
Selection
01: Control terminal block (DrivePro-
gramming)
02: Digital Operator
03: Modbus communication
04: Option
02
Disabled
−
P. 5-21
A202
2nd RUN Command
Selection
02
Disabled
A003
1st Base Frequency
30.0 to 1st Maximum Frequency (A004)
60.0
(580.0)
*2
Disabled
Hz
P. 5-20
A203
2nd Base Frequency
30.0. to 2nd Maximum Frequency (A204)
60.0
(580.0)
*2
Disabled
Hz
A004
1st Maximum Fre-
quency
1st Base Frequency (A003) to 590.0
60.0
(580.0)
*2
Disabled
Hz
P. 5-20
A204
2nd Maximum Fre-
quency
2nd Base Frequency (A203) to 590.0
60.0
(580.0)
*2
Disabled
Hz
Analog
input
A005
O/OI Selection
00: Switch between O (Voltage) and OI
(Current)
02: Switch between O (Voltage) and vol-
ume
*1
03: Switch between OI (Current) and
volume
*1
00
Disabled
−
P. 7-22
A011
O Start Frequency
0.00 to 590.00
0.00
Enabled
Hz
P. 7-25
A012
O End Frequency
0.00 to 590.00
0.00
Enabled
Hz
A013
O Start Ratio
0. to O End Ratio
0.
Enabled
%
A014
O End Ratio
O Start Ratio to 100.
100.
Enabled
%
A015
O Start Selection
00: O Start Frequency (A011)
01: 0 Hz
01
Enabled
−
A016
Analog Input Filter
1. to 30.
31. (500-ms filter with ±0.1-Hz hystere-
sis)
8.
Enabled
−
P. 7-24
DriveProgramming
A017
DriveProgramming
Function Selection
00: Disabled
01: Enabled (Start/stop via multi-func-
tion input PRG terminal)
02: Enabled (Start/stop via power on/
off)
00
Enabled
−
P. 7-105
*1. This setting is enabled when the Digital Operator with the volume control (Model: 3G3AX-OP01) is connected.
*2. In high-frequency mode.
4
4-3 Extended Function Mode
4-3-1 Group A: Standard Function Parameters
