*2. The management inverter sends the master switching command from Inverter No. 01 to 02 after data is sent
from Inverter 01 (master) to a slave (or slaves), with a wait time of “silent interval + Communication Wait Time
(C078).
*3. After receiving data from the master inverter, the management inverter sends the next master switching com-
mand with a wait time of “silent interval + Communication Wait Time (C078). If the management inverter can-
nnot receive the data sent from the master inverter within the Communication Error Timeout Time (C077), a
communication timeout occurs and the management inverter follows the operation set in the Operation Selec-
tion on Communication Error (C076).
*4. Be sure to enable the Communication Error Timeout Time setting (C077 = 0.01 to 99.99) on the management
inverter. When this setting is disabled (C077 = 0), the co-inverter communication will stop if the management
inverter cannot receive data from the master. In this case, cycle the power supply for the management
inverter, or reset the management inverter (by turning ON/OFF the terminal RS).
8-8-1 Co-inverter Communication Parameters
The parameters required to establish co-inverter communication are shown in the table below.
Parameter No.
Function name
Data
Default
data
Unit
Setting
target
*1
C072
*2
Communication
Station No. Selection
1. to 247.
*3
1.
−
ALL
*4
C076
*5
Operation Selection on
Communication Error
00: Trip
01: Trip after deceleration stop
02: Ignore
03: Free-run stop
04: Deceleration stop
02
−
ALL
C077
Communication Error
Timeout Time
0.00: Timeout disabled
0.01 to 99.99
0.00
s
ALL
C078
Communication Wait
Time
0. to 1000.
0.
ms
ALL
C096
*2
Communication Selec-
tion
00: Modbus communication
01: Co-inverter communication
02: Co-inverter communication
(management inverter)
00
−
−
B
A
C098
*2
Co-inverter Communi-
cation Starting Station
Number
1. to 8.
Setting required only for manage-
ment inverter
*6
1.
−
A
C099
*2
Co-inverter Communi-
cation Ending Station
Number
1. to 8.
Setting required only for manage-
ment inverter
*6
1.
−
A
C100
*2
Co-inverter Communi-
cation Start Selection
00:
Start via 485 terminal
*7
01:
Constant communication
*8
00
−
A
A
P140
Number of Sent Data
of All Stations in
Co-inverter Communi-
cation
1 to 5
5
−
M
P141
Recipient Station
Number of All Stations
in Co-inverter Commu-
nication 1
1 to 247
*9
1
−
M
P142
Recipient Register of
All Stations in
Co-inverter Communi-
cation 1
0000 to FFFF
0000
−
M
