8 Communications Functions
8 - 33
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter No.
Function name
Data
Default
data
Unit
Setting
target
*1
P143
Sender Register of All
Stations in Co-inverter
Communication 1
0000 to FFFF
0000
−
M
P144
Recipient Station
Number of All Stations
in Co-inverter Commu-
nication 2
1 to 247
2
−
M
P145
Recipient Register of
All Stations in
Co-inverter Communi-
cation 2
0000 to FFFF
0000
−
M
P146
Sender Register of All
Stations in Co-inverter
Communication 2
0000 to FFFF
0000
−
M
P147
Recipient Station
Number of All Stations
in Co-inverter Commu-
nication 3
1 to 247
3
−
M
P148
Recipient Register of
All Stations in
Co-inverter Communi-
cation 3
0000 to FFFF
0000
−
M
P149
Sender Register of All
Stations in Co-inverter
Communication 3
0000 to FFFF
0000
−
M
P150
Recipient Station
Number of All Stations
in Co-inverter Commu-
nication 4
1 to 247
4
−
M
P151
Recipient Register of
All Stations in
Co-inverter Communi-
cation 4
0000 to FFFF
0000
−
M
P152
Sender Register of All
Stations in Co-inverter
Communication 4
0000 to FFFF
0000
−
M
P153
Recipient Station
Number of All Stations
in Co-inverter Commu-
nication 5
1 to 247
5
−
M
P154
Recipient Register of
All Stations in
Co-inverter Communi-
cation 5
0000 to FFFF
0000
−
M
P155
Sender Register of All
Stations in Co-inverter
Communication 5
0000 to FFFF
0000
−
M
C001 to C007
Multi-function Input 1
to 7 Selection
81: 485 (Start co-inverter com-
munication)
*7
−
−
A
*1. Below are the details of the setting target.
ALL: Setting required for all connected inverters
A: Setting required only for management inverter (Station No. 1)
B: Setting required for inverters other than management inverter (Station No. 1)
M: Setting required only for inverters set in C098 to C099 (= Inverters assigned with master role)
8
8-8 Co-inverter Communication
8-8-1 Co-inverter Communication Parameters
