Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
5-6-3 2-step Acceleration/Deceleration Function
•
Use the 2-step acceleration/deceleration function to switch between two acceleration/deceleration
time settings or change the acceleration/deceleration time on the way during acceleration/decelera-
tion.
•
The acceleration/deceleration time switching method can be selected from the following three.
•
A094/A294 = 00: Switch via 2CH terminal (multi-function input set to 09) (Example 1)
•
A094/A294 = 01: Switch by 2-step Acceleration/Deceleration Frequency (A095/A295/A096/A296)
(Example 2)
•
A094/A294 = 02: Switch only during forward/reverse switching (Example 3)
•
To switch via a multi-function input terminal, set one of the parameters C001 to C007 to 09 (2CH).
2nd Acceleration Time 2
*1
2nd Deceleration Time 2
*1
1st 2-step Acceleration/Deceleration
Selection
00: Switch via 2CH terminal
(multi-function input: 09)
(Example 1)
2nd 2-step Acceleration/Deceleration
Selection
*1
01: Switch by setting
(A095/A295/A096/A296)
(Example 2)
02: Switch only during for-
ward/reverse switching
(Example 3)
1st 2-step Acceleration Frequency
2nd
2-step Acceleration
Frequency
*1
1st 2-step Deceleration Frequency
2nd
2-step
Deceleration
Frequency
*1
F002, F202, F003, F203, C001 to C007
*1. To enable the switching to the 2nd Acceleration/Deceleration Time 2 and to 2nd 2-step Acceleration/Deceler-
ation Frequency, set one of the Multi-function Input 1 to 7 Selection (C001 to C007) to 08 (SET) and turn ON
that terminal.
*2. The digit shift display mode can be used.
*3. In high-frequency mode.
