4 Parameter List
4 - 10
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
DC injection
braking
A057
Startup DC Injection
Braking Power
0. to 100./70.
(Heavy load/Light load)
0.
Enabled
%
P. 7-93
A058
Startup DC Injection
Braking Time
0.0 to 60.0
0.0
Enabled
s
A059
*1
(Reserved)
2.0 to 15.0/10.0
(Heavy load/Light load)
5.0/2.0
Enabled
kHz
Limit, jump
A061
1st Frequency Upper
Limit
0.00
1st Frequency Lower Limit to 1st Maxi-
mum Frequency
0.00
Enabled
Hz
P. 5-30
A261
2nd Frequency
Upper Limit
0.00
2nd Frequency Lower Limit to 2nd Maxi-
mum Frequency
0.00
Enabled
Hz
A062
1st Frequency Lower
Limit
0.00
Starting Frequency to 1st Frequency
Upper Limit
0.00
Enabled
Hz
A262
2nd Frequency
Lower Limit
0.00
Starting Frequency to 2nd Frequency
Upper Limit
0.00
Enabled
Hz
A063
Jump Frequency 1
0.00 to 590.00
0.00
Enabled
Hz
P. 7-36
A064
Jump Frequency
Width 1
0.00 to 10.00 (100.00)
*2
0.50
Enabled
Hz
A065
Jump Frequency 2
0.00 to 590.00
0.00
Enabled
Hz
A066
Jump Frequency
Width 2
0.00 to 10.00 (100.00)
*2
0.50
Enabled
Hz
A067
Jump Frequency 3
0.00 to 590.00
0.00
Enabled
Hz
A068
Jump Frequency
Width 3
0.00 to 10.00 (100.00)
*2
0.50
Enabled
Hz
Acceleration
stop
A069
Acceleration Stop
Frequency
0.00 to Starting Frequency: Disabled
Frequency above Starting Frequency to
99.99
100.0 to 590.00
0.00
Enabled
Hz
P. 7-37
A070
Acceleration Stop
Time
0.0: Disabled
0.1 to 60.0
0.0
Enabled
s
PID Braking
A071
PID Selection
00: Disabled
01: Enabled
02: Enabled (Reverse output enabled)
00
Enabled
−
P. 7-44
A072
PID P Gain
0.00 to 25.00
1.00
Enabled
−
A073
PID I Gain
0.0 to 3600.0
1.0
Enabled
s
A074
PID D Gain
0.00 to 100.00
0.00
Enabled
s
A075
PID Scale
0.01 to 99.99
1.00
Enabled
time
A076
PID Feedback Selec-
tion
00: OI (Current)
01: O (Voltage)
02: Modbus communication
03: Pulse train frequency
10: Operation function output
00
Enabled
−
*1. Changing it does not affect the operation of the 3G3MX2-EV2 Series Inverter.
*2. In high-frequency mode.
