1 - 11
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
3-phase 200 V, 11 kW
3-phase 400 V, 11/15 kW
(1)
3-phase 200 V, 15 kW
(1)
(1) Cooling Fin (4) Front Cover
(2) Inverter Case (5) Backing Plate
(3) Terminal Block Cover (6) Cooling Fan
1 Overview
1
(6)
(6)
(3)
4)
(5)
(2)
(6)
(6)
(3)
(4)
(5)
(2)
1-2 Appearance and Part Names
