8 Communications Functions
8 - 44
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus register
spec. No
Function name
Parameter No.
R/W
Monitor or setting
data
Data
resolution
003A hex
0039 hex
Fault Monitor 5 Fault
Factor
d085
R
Refer to Inverter trip
fault factor list on
page 8-46.
−
003B hex
003A hex
Fault Monitor 5 Inverter
Status
Refer to Inverter trip
fault factor list on
page 8-46.
−
003C hex
003B hex
Fault Monitor 5 Frequency
(HIGH)
0 to 59000
0.01
[Hz]
003D hex
003C hex
Fault Monitor 5 Frequency
(LOW)
003E hex
003D hex
Fault Monitor 5 Output
Current
Output current
value at the time of
trip
0.01 [A]
003F hex
003E hex
Fault Monitor 5 Main circuit
DC voltage
DC input voltage at
the time of trip
0.1 [V]
0040 hex
003F hex
Fault Monitor 5 Total RUN
Time (HIGH)
Total RUN time
before the trip
1 [h]
0041 hex
0040 hex
Fault Monitor 5 Total RUN
Time (LOW)
0042 hex
0041 hex
Fault Monitor 5 Total
Power ON Time (HIGH)
Total power ON
time before the trip
1 [h]
0043 hex
0042 hex
Fault Monitor 5 Total
Power ON Time (LOW)
0044 hex
0043 hex
Fault Monitor 6 Fault
Factor
d086
R
Refer to Inverter trip
fault factor list on
page 8-46.
−
0045 hex
0044 hex
Fault Monitor 6 Inverter
Status
Refer to Inverter trip
fault factor list on
page 8-46.
−
0046 hex
0045 hex
Fault Monitor 6 Frequency
(HIGH)
0 to 59000
0.01
[Hz]
0047 hex
0046 hex
Fault Monitor 6 Frequency
(LOW)
0048 hex
0047 hex
Fault Monitor 6 Output
Current
Output current
value at the time of
trip
0.01 [A]
0049 hex
0048 hex
Fault Monitor 6 Main circuit
DC voltage
DC input voltage at
the time of trip
0.1 [V]
004A hex
0049 hex
Fault Monitor 6 Total RUN
Time (HIGH)
Total RUN time
before the trip
1 [h]
004B hex
004A hex
Fault Monitor 6 Total RUN
Time (LOW)
004C hex
004B hex
Fault Monitor 6 Total
Power ON Time (HIGH)
Total power ON
time before the trip
1 [h]
004D hex
004C hex
Fault Monitor 6 Total
Power ON Time (LOW)
004E hex
004D hex
Warning Monitor
d090
R
Warning code
−
004F to
08FF hex
−
Not used
−
−
Not accessible
−
