Omron 3G3MX2-A2002-EV2 - Page 536

8 Communications Functions
8 - 92
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
16B7 hex
16B6 hex
(Reserved)
P181
−
Do not change the
default 0.
−
−
16B8 hex
16B7 hex
(Reserved)
P182
−
Do not change the
default 0.
−
−
16B9 hex
16B8 hex
(Reserved)
P183
−
Do not change the
default 0.
−
−
16BA hex
−
Reserved
−
−
−
−
−
16BB hex
16BA hex
(Reserved)
P185
−
Do not change the
default 0.
−
−
16BC hex
16BB hex
(Reserved)
P186
−
Do not change the
default 6.
−
−
16BD to
16BF hex
−
Not used
−
−
Not accessible
−
−
16C0 hex
16BF hex
(Reserved)
P190
−
Do not change the
default 0.
−
−
16C1 hex
−
Not used
−
−
Not accessible
−
−
16C2 hex
16C1 hex
(Reserved)
P192
−
Do not change the
default 63.
−
−
16C3 hex
−
Not used
−
−
Not accessible
−
−
16C4 hex
16C5 hex
16C4 hex
(Reserved)
P195
−
Do not change the
default 0.
−
−
16C6 hex
16C5 hex
(Reserved)
P196
−
Do not change the
default 21.
−
−
16C7 hex
−
Not used
−
−
Not accessible
−
−
16C8 hex
16C7 hex
Modbus Mapping
Function Selection
P200
R/W
00: Standard Modbus
address
01: Modbus mapping
enabled
−
P. 8-24
16C9 hex
16C8 hex
Modbus Mapping
External Register 1
P201
R/W
0000 to FFFF hex
1
16CA hex
16C9 hex
Modbus Mapping
External Register 2
P202
R/W
0000 to FFFF hex
1
16CB hex
16CA hex
Modbus Mapping
External Register 3
P203
R/W
0000 to FFFF hex
1
16CC hex
16CB hex
Modbus Mapping
External Register 4
P204
R/W
0000 to FFFF hex
1
16CD hex
16CC hex
Modbus Mapping
External Register 5
P205
R/W
0000 to FFFF hex
1
16CE hex
16CD hex
Modbus Mapping
External Register 6
P206
R/W
0000 to FFFF hex
1
16CF hex
16CE hex
Modbus Mapping
External Register 7
P207
R/W
0000 to FFFF hex
1
16D0 hex
16CF hex
Modbus Mapping
External Register 8
P208
R/W
0000 to FFFF hex
1
16D1 hex
16D0 hex
Modbus Mapping
External Register 9
P209
R/W
0000 to FFFF hex
1
16D2 hex
16D1 hex
Modbus Mapping
External Register 10
P210
R/W
0000 to FFFF hex
1
