Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
The main functions of the DriveProgramming Editor available in CX-Drive are as shown below.
Supports the creation, editing, saving, reading, and printing of user programs.
Compiles a user programs.
*1
Downloads a user program to the inverter, or
uploads a user program from the inverter.
Starts and stops the execution of a program.
This allows the user to check the inverter status monitor etc.
*1. Compilation is the process to generate an intermediate code after a program check.
For details, refer to “DriveProgramming User’s Manual (I580).”
9 Overview of DriveProgramming
Creation, editing and saving of
user programs
Connect directly or
via communications
Program execution
Monitor
Parameter changed
CX-Drive
Ver. 3.02 or higher
9-1 Overview of DriveProgramming
