Appendices

A - 12

Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)

•

Non-Semiconductor Fuse (for SCCR ≤ 5kA)

Model No.

MODE

Fuse Type

Rated

voltage

Rated

current

3G3MX2-AB001-EV2

Class J, CC, G, T

600VAC

3G3MX2-AB002-EV2

3G3MX2-AB004-EV2

10A

3G3MX2-AB007-EV2

20A

3G3MX2-AB015-EV2

30A

3G3MX2-AB022-EV2

30A

3G3MX2-A2001-EV2

3G3MX2-A2002-EV2

3G3MX2-A2004-EV2

10A

3G3MX2-A2007-EV2

15A

3G3MX2-A2015-EV2

15A

3G3MX2-A2022-EV2

20A

3G3MX2-A2037-EV2

30A

3G3MX2-A2055-EV2

Class J, G, T

600VAC

60A

3G3MX2-A2075-EV2

60A

3G3MX2-A2110-EV2

Class J, T

600VAC

80A

3G3MX2-A2150-EV2

100A

3G3MX2-A4004-EV2

Class J, CC, G, T

600VAC

3G3MX2-A4007-EV2

10A

3G3MX2-A4015-EV2

10A

3G3MX2-A4022-EV2

10A

3G3MX2-A4030-EV2

15A

3G3MX2-A4040-EV2

15A

3G3MX2-A4055-EV2

30A

3G3MX2-A4075-EV2

30A

3G3MX2-A4110-EV2

Class J, G, T

600VAC

50A

3G3MX2-A4150-EV2

50A
