C-mode Command Details Section 4-3
4-3-11 LR AREA WRITE – – WL
Writes data to the Link Area (CIO 1000 to CIO 1199) starting from the speci-
fied word. Writing is done in word units.
Command Format
Response Forma
Execution Conditions
End Codes An end code of 14 (format error) will be returned if the length of the command
is incorrect.
An end code of 15 (entry number data error) will be returned if the specified
write data exceeds the data area boundary, the beginning word is not speci-
fied in BCD, or the write data is not hexadecimal. (An end code of A5 will be
returned instead of 15 for non-hexadecimal write data in multiple command
frames.)
Note The command is provided for compatibility with previous models. We recom-
mend using CIO AREA WRITE (WR) whenever possible.
@
FCS
WL
x 10
1
x 10
0
x 10
3
x 10
2
* ↵
x 10
1
x 10
0
x 16
3
x 16
2
x 16
1
x 16
0
Unit No. (BCD)
Header
code
TerminatorWrite data (1 word)
Write data
(
for number of words to write
)
Beginning word
(000 to 0199)
@
FCS
WL
x 10
1
x 10
0
x 16
1
x 16
0
* ↵
Unit No. (BCD)
End codeHeader
code
Terminator
Commands Responses PLC Mode UM Area
Single Multiple Single Multiple RUN MON PROG Write-protected Read-protected
OK OK OK No No OK OK OK OK
End code (Hex) Contents
00 Normal completion
01 Not executable in RUN mode
13 FCS error
14 Format error
15 Entry number data error
18 Frame length error
21 Not executable due to CPU Unit CPU error.
A3 Aborted due to FCS error in transmit data
A4 Aborted due to format error in transmit data
A5 Aborted due to entry number data error in transmit data
A8 Aborted due to frame length error in transmit data
