C-mode Command Details Section 4-3
4-3-26 FORCED SET – – KS
Force sets the operating status of operands. (Only one bit at a time can be
force set.)
Command Format
Note “SP” represents a space (20 Hex).
Response Format
Execution Conditions
End Codes An end code of 14 (format error) will be returned if the length of the command
is incorrect, or if the bit is designated as other than 00 by the TIM/CNT desig-
nation.
An end code of 15 (entry number data error) will be returned if the area classi-
fication, word address, or bit parameter setting is out of range (including hexa-
decimal data).
19 Not executable
21 Not executable due to CPU Unit CPU error.
End code (Hex) Contents
Classifica-
tion
Area classification Word
address
Bit
Charac-
ter 1
Charac-
ter 2
Charac-
ter 3
Charac-
ter 4
CIO C I O (SP) 0000 to 6143 00 to 15
LR L R (SP) (SP) 0000 to 0199 00 to 15
WR W R (SP) (SP) 0000 to 0511 00 to15
HR H R (SP) (SP) 0000 to 0511 00 to 15
Timer T I M (SP) 0000 to 2047 Always
00
Counter C N T (SP) 0000 to 2047 Always
00
@KS
x 10
0
x 10
1
x 10
3
x 10
2
x 10
1
x 10
0
x 10
1
x 10
0
↵*
OP1 OP2 OP3
OP4
Unit No. (BCD)
Header
code
TerminatorFCS
Area classification Word address
Bit
@KS
x 10
0
x 10
1
x 16
1
x 16
0
↵*
Unit No. (BCD)
Header
code
TerminatorFCS
End code
Commands Responses PLC Mode UM Area
Single Multiple Single Multiple RUN MON PROG Write-protected Read-protected
OK No OK No No OK OK OK OK
End code (Hex) Contents
00 Normal completion
01 Not executable in RUN mode
13 FCS error
14 Format error
15 Entry number data error
18 Frame length error
21 Not executable due to CPU Unit CPU error.
