FINS Commands Section 5-3
Number of Units (response)
The number of Units for which the connection data is being returned. If bit 7 is
ON (1), it means that the data for the last Unit is being returned. The maxi-
mum setting is 19 hex (25). If the number of items is not specified, 19 hex (25)
will be used.
Unit address and model number (response)
These response parameters show the unit address and model number. The
model number is provided in up to 20 ASCII characters.
End code (response)
Refer to 5-1-3 End Codes for information on end codes.
5-3-17 CPU UNIT STATUS READ: 06 01
Reads the operating status of the CPU Unit.
Execution Conditions
Command Format
Response Format
Parameters Status (response)
The operating status of the CPU Unit is as shown below. Bits 3 to 6 are unde-
fined. Always mask these bits before accessing them.
Access right at
other device
UM read
protection
DIP switch UM write
protection
Network write
protection
OK OK OK OK
RUN mode MONITOR mode PROGRAM mode
OK OK OK
Command
code
01
06
0106
Mode
Message
Yes/no
Error
code
Error
message
Status
End codeCommand
code
Fatal error
data
Non-fatal
error data
16 bytes
76543210
Bit
Status
0: Stop (user program is not being executed)
1: Run (user program is being executed)
Built-in flash memory access (CS1-H, CJ1-H, CJ1M, CP1H, NSJ, and CS1D only)
0: Not writing, 1: Writing
Battery status (CS1-H, CJ1-H, CJ1M, CP1H, NSJ, and CS1D only)
0: No battery, 1: Battery present
CPU status
0: Normal
1: CPU on standby
(waiting for a signal from a device,
such as a SYSMAC BUS Remote I/O Slave Unit
)
.
Undefined
−−− −
