144
C-mode Command Details Section 4-3
End Codes An end code of 14 (format error) will be returned if the length of the command
is incorrect (the total size of the program is not a multiple of 8 bytes) or the first
frame contains no program data.
An end code of 15 (entry number data error) will be returned if the specified
write data is not hexadecimal.
4-3-34 I/O TABLE GENERATE – – MI
Corrects the registered I/O table to match the actual I/O table.
Command Format
Response Format
Limitations The UM write-protected end code for this command is different from that of
the other commands.
Execution Conditions
End Codes An end code of 14 (format error) will be returned if the length of the command
is incorrect.
End code (Hex) Contents
00 Normal completion
01 Not executable in RUN mode
02 Not executable in MONITOR mode
13 FCS error
14 Format error
15 Entry number data error
18 Frame length error
19 Not executable
21 Not executable due to CPU Unit CPU error.
23 User memory protected
A3 Aborted due to FCS error in transmit data
A4 Aborted due to format error in transmit data
A5 Aborted due to entry number data error in transmit data
A8 Aborted due to frame length error in transmit data
@MI
x 10
0
x 10
1
↵*
Unit No. (BCD)
Header
code
TerminatorFCS
@MI
x 10
0
x 10
1
x 16
1
x 16
0
↵*
Unit No. (BCD)
Header
code
End code TerminatorFCS
Commands Responses PLC Mode UM Area
Single Multiple Single Multiple RUN MON PROG Write-protected Read-protected
OK No OK No No No OK No OK
End code (Hex) Contents
00 Normal completion
01 Not executable in RUN mode
02 Not executable in MONITOR mode
03 UM write-protected
13 FCS error
To Next Page
