C-mode Command Details Section 4-3
will also be returned if the a data specification of 0 or 1 is used when a timer
or counter is designated.
4-3-29 FORCED SET/RESET CANCEL – – KC
Cancels all forced set and forced reset bits (including those set by FORCED
SET, FORCED RESET, and MULTIPLE FORCED SET/RESET).
Command Format
Response Format
Execution Conditions
End Codes An end code of 14 (format error) will be returned if the length of the command
is incorrect. (The forced set/reset/cancel data can be 16 bytes long.)
End code (Hex) Contents
00 Normal completion
01 Not executable in RUN mode
13 FCS error
14 Format error
15 Entry number data error
18 Frame length error
21 Not executable due to CPU Unit CPU error.
@ K C
x 10
0
x 10
1
↵*
Unit No. (BCD) Header
code
TerminatorFCS
@KC
x 10
0
x 10
1
x 16
1
x 16
0
↵*
Unit No. (BCD) Header
code
TerminatorFCSEnd code
Commands Responses PLC Mode UM Area
Single Multiple Single Multiple RUN MON PROG Write-protected Read-protected
OK No OK No No OK OK OK OK
End code (Hex) Contents
00 Normal completion
01 Not executable in RUN mode
13 FCS error
14 Format error
15 Entry number data error
18 Frame length error
21 Not executable due to CPU Unit CPU error.
