198
FINS Commands Section 5-3
Day of week: As follows:
End code (response)
Refer to 5-1-3 End Codes for information on end codes.
Comments If the second and the day of week are not specified, 00 (BCD) will be set as
the second and the previous value will be kept for the day.
If the second is specified, but the day of week is omitted, the previous setting
will not be changed.
The PLC does not check the day of week from the day of month. This means
that no error will occur even if the day of month and the day of week do not
agree.
The PLC automatically checks the range of the specified data. If any portion
of the data is incorrect, the clock will not be set.
5-3-21 MESSAGE READ: 09 20
Reads messages generated by MSG(195).
Execution Conditions
Command Format
Response Format
Parameters Message number parameter (command and response)
In the command format, turn ON (1) the bits of the messages to be read. In
the response format, the bits of the messages being returned will be ON (1). If
no bits are turned ON in the command format, all bits will be OFF (0) in the
response format and no further data will be returned.
Value (hex)00010203040506
Day of week Sun Mon Tues Wed Thur Fri Sat
Access right at
other device
UM read
protection
DIP switch UM write
protection
Network write
protection
OK OK OK OK
RUN mode MONITOR mode PROGRAM mode
OK OK OK
2009
Message No.
parameter
Command
code
2009
Message MessageEnd code Message No.
parameter
Command
code
32 bytes 32 bytes
