Command Lists Section 5-1
5-1-2 FINS Command Restrictions
Type Command
code
Name PLC status
RUN
mode
MONI-
TOR
mode
PRO-
GRAM
mode
Access
right
Read
protec-
tion
DIP
switch
UM
write-
protec-
tion
Write-
pro-
tected
from
network
MR SR
I/O memory
area access
01 01 MEMORY AREA READ OK OK OK OK OK OK OK
02 MEMORY AREA WRITE OK OK OK OK OK OK Disabled
03 MEMORY AREA FILL OK OK OK OK OK OK Disabled
04 MULTIPLE MEMORY
AREA READ
OK OK OK OK OK OK OK
05 MEMORY AREA
TRANSFER
OK OK OK OK OK OK Disabled
Parameter
area access
02 01 PARAMETER AREA
READ
OK OK OK OK OK OK OK
02 PARAMETER AREA
WRITE
OK OK OK Disabled OK Disabled Disabled
03 PARAMETER AREA
CLEAR
OK OK OK Disabled OK Disabled Disabled
Program
area access
03 06 PROGRAM AREA
READ
OK OK OK OK Disabled OK OK
07 PROGRAM AREA
WRITE
Disabled Disabled OK Disabled OK Disabled Disabled
08 PROGRAM AREA
CLEAR
Disabled Disabled OK Disabled OK Disabled Disabled
Operating
mode
changes
04 01 RUN OK OK OK Disabled OK OK Disabled
02 STOP OK OK OK Disabled OK OK Disabled
Machine
configuration
reading
05 01 CPU UNIT DATA READ OK OK OK OK OK OK OK
02 CONNECTION DATA
READ
OK OK OK OK OK OK OK
Status
reading
06 01 CPU UNIT STATUS
READ
OK OK OK OK OK OK OK
20 CYCLE TIME READ OK OK Disabled OK OK OK OK
Time data
access
07 01 CLOCK READ OK OK OK OK OK OK OK
02 CLOCK WRITE OK OK OK Disabled OK OK
Message
display
09 20 MESSAGE READ/
CLEAR
OK OK OK Dis-
abled
(MES-
SAGE
CLEAR
only)
OK OK Disabled
Access rights 0C 01 ACCESS RIGHT
ACQUIRE
OK OK OK Disabled OK OK Disabled
02 ACCESS RIGHT
FORCED ACQUIRE
OK OK OK OK OK OK OK
03 ACCESS RIGHT
RELEASE
OK OK OK OK OK OK OK
Error log 21 01 ERROR CLEAR OK OK OK Disabled OK OK Disabled
02 ERROR LOG READ OK OK OK OK OK OK OK
03 ERROR LOG CLEAR OK OK OK OK OK OK Disabled
