188
FINS Commands Section 5-3
5-3-13 RUN: 04 01
Changes the CPU Unit’s operating mode to MONITOR or RUN, enabling the
PLC to execute its program.
Note The CPU Unit will start operation when RUN is executed. You must confirm
the safety of the system before executing RUN.
When the "prohibit overwriting of protected program" setting is enabled, this
command cannot be executed.
Execution Conditions
Command Format
Response Format
Parameters Program number (command)
Always FFFF (hex).
Mode (command)
Set the CPU Unit’s operating mode as follows:
02 (hex): Change to MONITOR mode.
04 (hex): Change to RUN mode.
End code (response)
Refer to 5-1-3 End Codes for information on end codes.
Comments If only the command code or only the command code and program number
are sent, the mode will be changed to MONITOR mode.
If the CPU Unit’s operating mode has already been changed to the intended
mode when this command is sent, a normal completion will be returned.
5-3-14 STOP: 04 02
Changes the CPU Unit’s operating mode to PROGRAM, stopping program
execution.
Note The CPU Unit will stop operation when STOP is executed. You must confirm
the safety of the system before executing STOP.
Access right at
other device
UM read
protection
DIP switch UM write
protection
Network write
protection
No OK OK No
RUN mode MONITOR mode PROGRAM mode
OK OK OK
0104 FF FF
Program
No.
Command
code
Mode
0104
End codeCommand
code
To Next Page
