175
FINS Commands Section 5-3
I/O Memory Area Codes
Note On a CJ2 CPU unit only, 50 to 5F can be specified for the memory area code
of EM banks 0 to F.
5-3-4 MEMORY AREA FILL: 01 03
Writes the same data to the specified number of consecutive memory area
words.
Execution Conditions
Command Format
Area Data type CS/CJ mode
memory area
code (hex)
CV mode
memory area
code (hex)
Bytes per
element
CIO Area CIO Bit 30 --- 1
Work Area WR 31 ---
Holding Bit Area HR 32 ---
Auxiliary Bit Area AR 33 ---
CIO Area CIO Word B0 80 2
Work Area WR B1 ---
Holding Bit Area HR B2 ---
Auxiliary Bit Area AR B3 80
Timer Area TIM PV 89 81 2
Counter Area CNT
DM Area DM Bit 02 --- 1
DM Word 82 82 2
EM Area EM bank 0 to
bank F
Bit 20 to 2F --- 1
EM bank 10 to
bank 18
E0 to E8 --- 1
EM bank 0 to
bank F
Word A0 to AF or
50 to 5F
(see note)
90 to 97 2
EM bank 10 to
bank 18
60 to 68 --- 2
EM current
bank
Bit 0A --- 1
Word 98 98 2
Index Register IR PV DC --- 4
Data Register DR PV BC 9C 2
Access right at
other device
UM read
protection
DIP switch UM
write protection
Network write
protection
OK OK OK No
RUN mode MONITOR mode PROGRAM mode
OK OK OK
Command
code
01
I/O memory area code
03
DataBeginning address No. of items
(binary)
