FINS Commands Section 5-3
Parameter (command)
Specify the transfer or verification method.
0000 (hex): Transfer (CPU Unit to Memory Cassette)
0001 (hex): Transfer (Memory Cassette to CPU Unit)
0002 (hex): Verify (between CPU Unit and Memory Cassette)
0003 (hex): Initialize Memory Cassette
8000 (hex): Read data type in Memory Cassette
Data type designation (command)
Bit 15: All or individual area designation (OFF: All, ON: Individual areas)
OFF: All areas for bits 00 and 02 through 07 (See note.)
ON: Only areas specified by bits 00 and 02 through 07 (Multiple bits
can be turned ON.)
Bits 14 to 08: Reserved
Bit 07: Data memory initial values
Bit 06: Data memory
Bit 05: Program indices
Bit 04: Comments
Bit 03: Symbol table
Bit 02: parameter area
Bit 01: Reserved
Bit 00: User program + Function block sources
Note If bit 15 is OFF and any of bit 02 or bits 02 to 07 is ON, an Other Parameter
Error will occur and an end code of 110C hex will be returned.
End code (response)
Refer to 5-1-3 End Codes for information on end codes.
Stored data type (response)
When reading the data type in the Memory Cassette (parameter = 8000 hex),
the following bits corresponding to the stored data will be turned ON. (More
than one bit may be turned ON.)
Bit 07: Data memory initial values
Bit 06: Data memory
Bit 05: Program indices
Bit 04: Comments
Bit 03: Symbol table
Bit 02: Parameter area
Bit 01: Function block sources
Bit 00: User program
5-3-44 FORCED SET/RESET: 23 01
Force-sets (ON) or force-resets (OFF) bits/flags or releases force-set status.
Bits/flags that are forced ON or OFF will remain ON or OFF and cannot be
written to until the forced status is released.
Execution Conditions
Note “Forced status” means that the ON/OFF status of the bit/flag is forcibly
retained and writing is prohibited.
Access right at
other device
UM read
protection
DIP switch UM
write protection
Network write
protection
OK OK OK No
RUN mode MONITOR mode PROGRAM mode
No OK OK
