230
FINS Commands Section 5-3
5-3-45 FORCED SET/RESET CANCEL: 23 02
Cancels all bits (flags) that have been forced ON or forced OFF.
Execution Conditions
Command Format
Response Format
End code (response)
Refer to 5-1-3 End Codes for information on end codes.
Comments The bits/flags in the following memory areas can be forced set or forced reset,
and canceled.
5-3-46 CONVERT TO COMPOWAY/F COMMAND: 28 03
When this command is sent to a CS/CJ-series CPU Unit with unit version 3.0
or later, serial port C on the Controller Section of an NSJ Controller, built-in
serial ports of N-type CP1E CPU Units, serial port 1 or 2 on an Option Board
of a CP-series CPU Unit, or a serial port on a Serial Communications Unit/
Board (version 1.2 or later), the CPU Unit or Serial Communications Unit/
Board removes the FINS header and sends the enclosed CompoWay/F com-
mand.
With this command, OMRON components connected to a PLC through Com-
poWay/F communications can be accessed from a PLC or PT by sending a
FINS message containing a CompoWay/F command.
Execution Conditions
Access right at
other device
UM read
protection
DIP switch UM write
protection
Network write
protection
OK OK OK No
RUN mode MONITOR mode PROGRAM mode
No OK OK
Command
code
23 02
Command
code
23
02
End code
Memory area Data
Relay areas Bit status
Timer/Counter Completion Flag status
Access right at
other device
UM read
protection
DIP switch UM write
protection
Network write
protection
OK OK OK OK
RUN mode MONITOR mode PROGRAM mode
OK OK OK
