224
FINS Commands Section 5-3
Absolute directory path (command)
Indicates the absolute path from the root directory. It begins with \ (5C hex),
and the drive name and colon (:) are not required. “\” is used to delimit the
lower directory. It is not required at the end of the final absolute path. No set-
ting is required to specify the root directory itself.
End code (response)
Refer to 5-1-3 End Codes for information on end codes.
Comments The clock data upon completion of a parameter area to file memory transfer
will be recorded as the date of the file that has been transferred.
A file can be transferred to the I/O table only when the CPU Unit is in PRO-
GRAM mode.
This command cannot be executed if any other device holds the access right.
Files cannot be overwritten when transferring data from the parameter area to
file memory.
5-3-41 PROGRAM AREA–FILE TRANSFER: 22 0C
Compares or transfers data between the program area and the file memory.
Execution Conditions
Note 1. Data can be transferred from the program area to the file memory.
2. Data cannot be transferred from file memory to the program area in these
modes.
Command Format
Response Format
Parameters Parameter code (command)
Specify the transfer/compare method as follows:
0000 (hex)
Data transfer from the program area to the file memory.
Access right at
other device
UM read
protection
DIP switch UM write
protection
Network write
protection
No OK No (See Note 1.) No
RUN mode MONITOR mode PROGRAM mode
OK (See note 2.) OK (See note 2.) OK
22 0C
File nameParameter
code
Program area specification File specification
Program
No.
Beginning word No. of bytes Disk No.
FF FF 00 00 00 00
Command
code
12 bytes
FF FF FF
FF
Directory
length
Absolute directory
path
Command
code
22
0C
End code Data length
