FINS Commands Section 5-3
5-3-43 MEMORY CASSETTE TRANSFER (CP-series CPU Units Only): 22 20
Transfers or verifies data between a Memory Cassette mounted in a CP-
series CPU Unit (see note) and the memory areas in the CP-series CPU Unit.
Transfers can go either direction.
Note
This command is supported only by CP-series CPU Units (Except CP1E CPU Units).
Execution Conditions
Note Data cannot be transferred from the CPU Unit to the Memory Cassette when
the user program is included and DIP switch UM protection is set.
Command Format
Response Format Other Memory Cassette Operations (Parameter
≠ 8000 Hex)
Reading the Data Type in the Memory Cassette (Parameter = 8000 Hex)
Parameters Disk number (command)
Specify the disk for transfer or verification. Only the Memory Cassette can be
specified.
8003 (hex): Memory Cassette
Applicable data Storage location in CPU Unit
User program RAM (user program area)
Parameter area (PLC Setup, CPU Bus Unit set-
tings, and routing tables)
RAM (parameter area)
Symbol table Built-in flash memory (Comment Memory Area)
Comments (I/O comments, row comments, and
annotations)
Built-in flash memory (Comment Memory Area)
Program indices (section names, section
comments, and program comments)
Built-in flash memory (Comment Memory Area)
Function block sources Built-in flash memory (Function Block Source Memory
Area)
Data memory RAM (DM Area D0 to D32767)
Data memory initial values Built-in flash memory (Data memory initial value area)
Access right at
other device
UM read
protection
DIP switch UM write
protection
Network write
protection
No OK OK (See note.) No
RUN mode MONITOR mode PROGRAM mode
No No OK
22 20
Disk number
MEMORY
CASSETTE
TRANSFER
Parameter Data type designation
22 20
End code
MEMORY
CASSETTE
TRANSFER
22 20
End code
MEMORY
CASSETTE
TRANSFER
Stored data type
