FINS Commands Section 5-3
Command Format
Response Format
Parameters Command
Node Number
This is the destination ID number (00 to 99 or XX) in the CompoWay/F sys-
tem. The characters are specified in ASCII. When sending a broadcast trans-
mission, set the node number to XX (two X's).
Subaddress
The subaddress is 00 for most models and the value is specified in ASCII as
3030 hex. For some models, other values must be set.
CompoWay/F SID (Service ID)
The Service ID is 0 for most models and the value is specified in ASCII as 30
hex. For some models, other values must be set.
CompoWay/F Command Code
This is the CompoWay/F command code. For details, refer to the command
manual for the CompoWay/F Slave.
CompoWay/F Text (Command and Response)
This is the data that follows the command code.
Response
Node Number
This is the destination ID number (00 to 99 or XX) in the CompoWay/F sys-
tem. The characters are specified in ASCII. When a broadcast transmission is
sent, the node number is set to XX (two X's).
Subaddress
The subaddress is 00 for most models and the value is specified in ASCII as
3030 hex. For some models, other values must be set.
CompoWay/F SID (Service ID)
The Service ID is 0 for most models and the value is specified in ASCII as 30
hex. For some models, other values must be set.
End Code (Response)
The end code indicates the command frame's execution result. (The end code
is not the same as the response code, which is described below.)
30 28 03 30 30
Command
code
Node
number
(ASCII)
Subaddress:
00
(3030 in
ASCII)
CompoWay/
F
SID: 0
(30 in
ASCII
To Next Page
