129
C-mode Command Details Section 4-3
Note “SP” represents a space (20 Hex).
Note “SP” represents a space (20 Hex).
Response Format
Parameters Program Address (Command)
Designate the program address in four digits decimal (BCD) for beginning the
search for the specified timer/counter instruction.
Timer/Counter Type (Command)
Designate the timer/counter instruction type for changing the constant SV or
the word address in which it is stored.
Timer/Counter Number (Command)
Designate the timer/counter instruction number for reading the constant SV.
(Index register designation is not possible.) The range that can be designated
is the same as for R#.
Constant/Area Classification (Command)
Designate the ASCII characters to express the new SV area classification or
constant.
New SV/Word Address (Command)
Designate the newly set constant SV or the word address in which it is stored.
Limitations Timers T2048 to T4095 and counters C2048 to C4095 cannot be read.
The SV of the first timer/counter found after the designated program address
will be read.
If the SV is outside of range for the timer/counter type or number, an end code
of 16 (command not supported) will be returned.
Classification Constant/area classification SV or word
address
(BCD)
Charac-
ter 1
Charac-
ter 2
Charac-
ter 3
Charac-
ter 4
Constant C O N (SP) 0000 to 9999
CIO C I O (SP) 0000 to 6143
AR A R (SP) (SP) 0000 to 0959
HR H R (SP) (SP) 0000 to 0511
WR W R (SP) (SP) 0000 to 0511
Timer T I M (SP) 0000 to 2047
Counter C N T (SP) 0000 to 2047
DM D M (SP) (SP) 0000 to 9999
DM (indirect) D M
*
(SP) 0000 to 9999
EM current bank E M (SP) (SP) 0000 to 9999
EM (indirect) current
bank
EM
*
(SP) 0000 to 9999
EM banks 0 to C E M 0 to C (SP) 0000 to 9999
EM (indirect) 0 to C E M 0 to C
*
0000 to 9999
Data register D R (SP) (SP) 0000 to 0015
Index register , I R (SP) 0000 to 0015
@W$
x 16
0
x 10
0
x 10
1
x 16
1
* ↵
Unit No. (BCD)
Header
code
TerminatorFCSEnd code
To Next Page
