182
FINS Commands Section 5-3
Command Format
Response Format
Parameters Parameter area code (command and response)
Specify the parameter area to write. The parameter area code is designated
in two bytes. The leftmost byte is always 80 (hex) and the rightmost byte spec-
ifies the parameter area.
Beginning word (command and response)
Specify the first word to write. The beginning word address specifies the rela-
tive word address, with the beginning of the designated area as 0000 (hex).
Parameter Areas
The areas that can be written to are shown below, along with their parameter
area codes.
Number of words (command)
Bits 0 to 14 are used to specify the number of words to be written. (Each word
consists of two bytes.) Bit 15 must be ON (1) when data is written to the last
word in the specified parameter area or no data will be written. If the number
of write words is set to 0000, no words will be written and a normal end code
will be returned.
Data (command)
The data to be written. The leftmost bits (bits 15 to 8) of each word must be
specified first, followed by the rightmost bits (bits 7 to 0). The required number
of bytes in total for each write can be calculated as follows:
No. of words x 2 (each word consists of two bytes)
End code (response)
Refer to 5-1-3 End Codes for information on end codes.
02 02
Parameter
area code
Beginning
word
No. of words
Data
Command
code
End codeCommand
code
02 02
PLC Setup Area
I/O Table Registration Area
Routing Table Area
CPU Bus Unit Setup Area
Parameter
area code
Address range
(Hex)
0000 to 01FF (512 words)
0000 to 04FF (1,280 words)
0000 to 01FF (512 words)
0000 to 143F (5184 words)
8010
8012
8013
8002
Parameter
area code
0000 to 1F3F
8000 words)
8000
Address range
(Hex)
Bits 0 to 7 (second byte)
Bits 8 to 15 (first byte)
Bit 15 OFF (0): Without last word data to be written.
Bit 15 ON (1): With last word data to be written.
Bits 0 to 14: No. of words to be written
To Next Page
