Omron E5CSV User Manual

Appendices
A-10
Appendices
■ Initial Setting Level (2)
Parameters
Mode
indicators
/displayed
text
Setting (monitor) value Default Unit
Set
value
Proportional band
SP mode
1 to 999 8 °C/°F
0 to 1999 233 Second Integral time
ALM mode
0 to 99 4 Minute
Derivative time
IS mode
0 to 1999 40 Second
■ Initial Setting Level (3)
Parameters
Mode
indicators
/displayed
text
Setting (monitor) value Default Unit
Set
value
Thermocouple
400
Platinum resistance
thermometer
99.9
Thermistor
100
SP upper limit SP mode SP lower limit + 1 to
Input range upper limit
Multi-input
(thermocouple/
platinum resistance
thermometer) models
1300
EU
Thermocouple
0
Platinum resistance
thermometer
0.0
Thermistor
0
SP lower limit ALM mode Input range lower limit
to SP upper limit − 1
Multi-input
(thermocouple/
platinum resistance
thermometer) models
−99
EU
0: Not assigned
1: Control function
2: Alarm 1 function
Control output
assignment
IS mode
ot
3: Alarm 2 function
1 None
0: Not assigned
1: Control function
2: Alarm 1 function
Alarm 1 assignment IS mode
a1
3: Alarm 2 function
2 None
0: Not assigned
1: Control function
2: Alarm 1 function
Alarm 2 assignment IS mode
a2
3: Alarm 2 function
3 None
