F3SG-SR/PG
51
Ratings and
Specifications
Connections
Extension cable
- Extended
Socket-Straight
Cable
- Extended Plug-
Socket Cable
Type of
connection
M12 connector type (5-pin emitter and 8-pin receiver), IP67 * rated when mated
* The extension cable meets the degree of protection when the root cable is correctly connected with the
extension cable. The degree of protection is not satisfied with the part where cable wires are uncovered.
Number of wires Emitter: 5, Receiver: 8
Cable length Refer to page 39
Cable diameter 6.6 mm
Minimum bending
radius
R36 mm
Cable extension
Refer to page 52 for restrictions on cable extension.
Root cable
In optical synchronization: 100 m max. * between power supply and emitter and between power supply
and receiver
In wired synchronization: 100 m max. * between power supply and emitter, between power supply and
receiver, and between emitter and receiver
* When the Intelligent Tap (F39-SGIT-IL3) is connected to the sensor, this applies in the case of the rated
power supply of 24 VDC to 24 VDC +20%.
Cascade
connection
Extension cable between sensors: 10 m max. (not including Cascading Cable for Extended *1 and Root
Cable *2.)
*1. F39-JGR3W
*2. F39-JGR3K
Material
Housing: Aluminum alloy
Cap: PBT resin
Front window: Acrylic resin
Side-Mount Bracket (Intermediate Bracket)(F39-LSGF): Zinc alloy
FE plate: Stainless steel
Weight Refer to page 55
Included accessories
Instruction Sheet, Quick Installation Manual, Troubleshooting Guide Sticker, Warning Zone Label, End Cap (for
switching Scan Code Selection function), Side-Mount Bracket (Intermediate Bracket) (F39-LSGF)
*
* The quantity varies depending on the protective height.
Protective height of 0160 to 1440: 2 sets (total 4 pcs), 1520 to 2480: 3 sets (total 6 pcs)
Conformity
Conforming standards Refer to page 62
Type of ESPE (IEC 61496-1)
F3SG-4SR-: Type 4
F3SG-2SR-: Type 2
Performance Level
(PL)/Safety category
F3SG-4SR-: PL e/Category 4 (EN ISO 13849-1:2015)
F3SG-2SR-: PL c/Category 2 (EN ISO 13849-1:2015)
PFHD F3SG-SR-: 1.1×10
-8
max. (IEC 61508)
Proof test interval TM Every 20 years (IEC 61508)
SFF 99% (IEC 61508)
HFT 1 (IEC 61508)
Classification Type B (IEC 61508-2)
Model
F3SG-@SRA@@@@-14
F3SG-@SRB@@@@-14
F3SG-@SRA@@@@-25
F3SG-@SRB@@@@-25
F3SG-@SRA@@@@-45
F3SG-@SRB@@@@-45
F3SG-@SRA@@@@-85
F3SG-@SRB@@@@-85
