F3SG-SR/PG
85
Dimensions
Side Mounting
46.7
2-M5
or M6
C
F
56.5
4.2
H
2-M8
<Screw for Adjustable
Top/Bottom Bracket: M8 *1>
19
19
56.5
4.2
F
C
G
4-M5
2-M5
or M6
<Screw for Adjustable
Top/Bottom Bracket: M5 *1>
3.2
32
F
C(Protective height)
N1
N2
10
P
D
5.8
6.3
1.7
9 dia.
4.2
56.5
G
H
19
38
73
10
50
I
4.2
H
Adjustable Side-Mount
Bracket (F39-LSGA)
Adjustable Top/Bottom
Bracket (F39-LSGTB-SJ)
Adjustable Top/Bottom
Bracket (F39-LSGTB-SJ)
*1. Adjustable Side-Mount Bracket: M5 or M6
*2. For the model of protective height of 0160, the numbers corresponding to dimensions N1 and N2 are 20 to 30.
*3. The number of brackets required to mount either one of emitter and receiver.
Dimension C 4-digit number of the type name (Protective height: )
Dimension D
F3SG-SR-14
C-20
F3SG-SR25
F3SG-SR-45
C-40
F3SG-SR-85
Dimension G C+27.2+N1+N2
Dimension H C+38+N1+N2
Dimension I C+58+N1+N2
Dimension N1 0 to 30 *2
Dimension N2 0 to 30 *2
Dimension P
F3SG-SR-14 10
F3SG-SR-25 20
F3SG-SR-45 40
F3SG-SR-85 80
Protective height
(Dimension C)
Number of
Adjustable
Top/Bottom
Bracket *3
Number of
Intermediate
Bracket *3
Dimension F
0160 to 0840 2 0 ---
0880 to1680 2 1 1000 mm max.
1760 to 2480 2 2 1000 mm max.
