Omron F3SG-SR Series - Mounting Bracket Dimensions

F3SG-SR/PG
86
Accessories
Bracket
Side-Mount Bracket (Intermediate Bracket) (F39-LSGF)
Adjustable Side-Mount Bracket (Intermediate Bracket) (F39-LSGA, sold separately)
Adjustable Top/Bottom Bracket (F3SJ, F3SN Adapter) (F39-LSGTB-SJ, sold separately)
13
5.7
14.7
30.7
34.4
13
8.2
30.7
6.5
41
37.5
12
6.3 dia.
6.3 dia.
Material:Zincalloy
Material: Zinc alloy
6.3
13
10
26.5
56.5
44.1
6.3
13
73
20
26.7
56.5
12
38.5
4.6
47.7
12
19
29
5.8
32
32
137
1.7
9 dia.
10
15.4
Material: High rolled steel (SPHC)
3.2
