Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
E163
Analog Operation Lev-
el at [AI1] Disconnec-
tion
-100 to 100 ％
999: Disable
32767 - %
page
7-103
E164
Analog Operation Lev-
el at [AI2] Disconnec-
tion
0 to 100 ％
999: Disable
32767 - %
page
7-103
E165
Carrier Frequency Au-
tomatic Reduction
Function Selection
0: Disable
1: Enable
1 - -
page
7-114
E166
Non-linear V/f Fre-
quency 1
0.0: Disable
0.1 to 590.0 Hz
0.0 - Hz
page
5-10
E167
Non-linear V/f Voltage
1
0 to 240 V (for 200 V class
series)
0 to 500 V (for 400 V class
series)
0 - V
page
5-10
E168
Non-linear V/f Fre-
quency 2
0.0: Disable
0.1 to 590.0 Hz
0.0 - Hz
page
5-10
E169
Non-linear V/f Voltage
2
0 to 240 V (for 200 V class
series)
0 to 500 V (for 400 V class
series)
0 - V
page
5-10
E170
Non-linear V/f Fre-
quency 3
0.0: Disable
0.1 to 590.0 Hz
0.0 - Hz
page
5-10
E171
Non-linear V/f Voltage
3
0 to 240 V (for 200 V class
series)
0 to 500 V (for 400 V class
series)
0 - V
page
5-10
4 Parameter List
4-97
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-2 Parameter E (Terminal Functions)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
