Item Three-phase 400 V
Rated output cur-
rent [A]
*5
HD 1.8 3.4 5 6.3 8.8 11.1 17.5 23 31 38 45 60
ND 2.1 4.1 5.5 6.9 9.2 12 21.5 28.5 37 44 59 72
HHD 1.8 3.4 4.8 5.5 7.2 9.2 14.8 18 24 31 39 45
HND
2.1 4.1 5.5
6.9
*7
8.8
11.1
*
7
17.5 23 31 38 45 60
Braking torque
[%]
*6
HD 53.3 68.2 47.7 29.3 29.3 26.9 15
ND 53.3 50.0 47.7 29.3 29.3 26.9 12
HHD 100 70 40 40 40 20
HND
53 68 48
29
*7
29
27
*7
15
Braking
resistor
circuit
Regenerative
braking
Built-in braking resistor circuit (discharge resistor separately mounted)
Minimum con-
nection resist-
ance [Ω]
200 160 to 200 130 to 200
80
min.
60
min.
40
min.
34.4
min.
16 min.
Short circuit current rating
[kA]
100
Weight [kg] 1.1 1.4 1.4 1.4 1.7 1.7 3.8 3.8 5.2 5.4 11 11
Dimensions (Width ×
Height) [mm]
110×130 140×130 180×220 220×260 250×400
Dimensions (Depth) [mm] 132 156 171 203 203
*1. The maximum applicable motor capacity is given for a standard four-phase motor. When selecting an inver-
ter, select not just by kW but also ensure that the inverter rated output current is greater than the motor rat-
ed current.
*2. In calculating the rated capacity
, the rated output voltage is assumed to be 380 V or 480 V.
*3. A voltage higher than the power supply voltage cannot be output.
*4. When Carrier Frequency (F26) is set to the following or below, derating is required.
HHD mode...A4004 to A4040: 8 kHz, A4055 to A4220: 10 kHz
HND mode...A4004 to A4040: 8 kHz, A4055 to A4185: 10 kHz, A4220: 6 kHz
HD and ND...modes All models: 4 kHz
For derating, refer to A-1 Derating Table on page A-2.
*5.
The following shows the calculated value when the power supply capacity is 500 kVA (10x the inverter ca-
pacity when the inverter capacity exceeds 50 kVA) and when a %X = 5% power supply is connected.
*6. The numeric value is the average braking torque per individual motor. (Varies according to motor efficiency)
*7. Allowable ambient temperature of 40°C or below of A4022 to A4040 in the HND mode.
The rated output current of A4022 and A4040 in the HND mode decreases by 1% for every temperature
increase of 1°C when the ambient temperature is 40°C or more.
Single-phase 200-V Class
HHD: Heavy load, HND: Light load
Item Single-phase 200 V
Model
(3G3M1-AB□□□)
001 002 004 007 015 022 037
