Omron R88A-MCW151-DRT-E - Page 256

241
Device Protocol (MCW151-DRT-E only) Appendix B
Item Section Information Max. number of instances
Object instance 1 Attribute Instance type Explicit Message 1
Production trigger Cyclic ---
Transport type Server
Transport class 3
Item ID content Get
(read)
Set
(write)
Value
Object instance 1 Attribute 1 State Yes No ---
2 Instance type Yes No 0000 (hexadecimal)
3 Transport class trigger Yes No 83 (hexadecimal)
4 Produced connection ID Yes No ---
5 Consumed connection ID Yes No ---
6 Initial comm. characteristics Yes No 21 (hexadecimal)
7 Produced connection size Yes No 00FE (hexadecimal)
8 Consumed connection size Yes No 00FE (hexadecimal)
9 Expected packet rate Yes Yes ---
12 Watchdog time-out action Yes No 01 (hexadecimal)
13 Produced connection path length Yes No 0000 (hexadecimal)
14 Produced connection path Yes No ---
15 Consumed connection path length Yes No 0000 (hexadecimal)
16 Consumed connection path Yes No ---
17 Production inhibit time Yes No 0000 (hexadecimal)
Item DeviceNet service Parameter option
Object instance 1 Service 05 Reset No
0E Get_Attribute_Single No
10 Set_Attribute_Single No
Item Section Information Max. number of instances
Object instance 2 Attribute Instance type Polled I/O 1
Production trigger Cyclic ---
Transport type Server
Transport class 2
