242
Device Protocol (MCW151-DRT-E only) Appendix B
Note The number of bytes for the consumed and the produced size depends on the
I/O Slave Messaging mode of the MC Unit. The mode set by pin 7 of the
DeviceNet switch settings.
MCW151 Object (0x8A)
Item ID content Get
(read)
Set
(write)
Value
Object instance 2 Attribute 1 State Yes No ---
2 Instance type Yes No 0100 (hexadecimal)
3 Transport class trigger Yes No 82 (hexadecimal)
4 Produced connection ID Yes No ---
5 Consumed connection ID Yes No ---
6 Initial comm. characteristics Yes No 01 (hexadecimal)
7 Produced connection size Yes No See note
8 Consumed connection size Yes No See note
9 Expected packet rate Yes Yes ---
12 Watchdog time-out action Yes No 0000 (hexadecimal)
13 Produced connection path length Yes No 0000 (hexadecimal)
14 Produced connection path Yes No No
15 Consumed connection path length Yes No 0000 (hexadecimal)
16 Consumed connection path Yes No No
17 Production inhibit time Yes No 0000 (hexadecimal)
Item DeviceNet service Parameter option
Object instance 2 Service 05 Reset No
0E Get_Attribute_Single No
10 Set_Attribute_Single No
Pin 7 I/O Slave
Messaging Mode
Connection size
OFF Mode I Produced connection size: Read area bytes (default
0004 (hexadecimal))
Consumed connection size: Write area bytes
(default 0004 (hexadecimal))
ON Mode II Produced connection size: Read area bytes (default
0008 (hexadecimal))
Consumed connection size: Write area bytes
(default 0008 (hexadecimal))
Object class Attribute Not supported
Service Not supported
Item ID content Get
(read)
Set
(write)
Value
Object instance 1 Attribute Yes Yes Need to perform ser-
vices on.
