3-11
3-1 Servo Drive Specifications
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
3
Specifications
R88D-KN06F-ML2/-KN10F-ML2/-KN15F-ML2/-KN20F-ML2
Main Circuit Connector Specifications (CNA)
Motor Connector Specifications (CNB)
Control Circuit Connector Specifications (CNC)
External Regeneration Resistor Connector Specifications (CND)
Symbol Name Function
L1 Main circuit power supply
input
R88D-KNxF-ML2
(600 W to 2 kW) : 3-phase: 380 to 480 VAC (323 to 528 V)
50/60 Hz
L2
L3
Symbol Name Function
U Motor connection
terminals
Phase U These are the output terminals to the Servomotor.
Be sure to wire them correctly.
V Phase V
W Phase W
Symbol Name Function
24 V Control circuit power
supply input
24 VDC ± 15%
0 V
Symbol Name Function
B1 External Regeneration
Resistor connection
terminals
Normally B2 and B3 are short-circuited.
If there is high regenerative energy, remove the short-circuit bar
between B2 and B3 and connect an External Regeneration
Resistor between B1 and B2.
B2
B3
NC Do not connect.
