3-5 External Regeneration Resistor Specifications
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
3
Specifications
3-5 External Regeneration Resistor
Specifications
External Regeneration Resistor Specifications
R88A-RR08050S
R88A-RR080100S
R88A-RR22047S1
Model
Resistance
value
Nominal
capacity
Regeneration
absorption for 120
 C
temperature rise
Heat radiation
condition
Thermal switch
output specifications
R88A-
RR08050S
50  80 W 20 W
Aluminum
350 350,
Thickness: 3.0
Operating temperature
150C  5% NC contact
Rated output (resistive
load):
125 VAC, 0.1 A max.
30 VDC, 0.1 A max.
(minimum current: 1 mA)
Model
Resistance
value
Nominal
capacity
Regeneration
absorption for 120  C
temperature rise
Heat radiation
condition
Thermal switch
output specifications
R88A-
RR080100S
100  80 W 20 W
Aluminum
350 350,
Thickness: 3.0
Operating temperature
150C  5% NC contact
Rated output (resistive
load):
125 VAC, 0.1 A max.
30 VDC, 0.1 A max.
(minimum current: 1 mA)
Model
Resistance
value
Nominal
capacity
Regeneration
absorption for 120
 C
temperature rise
Heat radiation
condition
Thermal switch
output specifications
R88A-
RR22047S1
47  220 W 70 W
Aluminum
350 350,
Thickness: 3.0
Operating temperature:
150C  5C
NC contact
Rated output
(resistiveload): 250 VAC,
0.2 A max.
42 VDC, 0.2 A max.
(minimum current: 1 mA)
