Omron R88D-KN ML2 Sries User Manual

3-2
3-1 Servo Drive Specifications
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
3
Specifications
Characteristics
100-VAC Input Type
*1. The heat value is given for rated operation.
Item
R88D-
KNA5L-ML2
R88D-
KN01L-ML2
R88D-
KN02L-ML2
R88D-
KN04L-ML2
Continuous output current (rms) 1.2 A 1.7 A 2.5 A 4.6 A
Input power
supply
Main
circuit
Power
supply
capacity
0.4 KVA 0.4 KVA 0.5 KVA 0.9 KVA
Power
supply
voltage
Single-phase 100 to 120 VAC (85 to 132 V) 50/60 Hz
Rated
current
1.7 A 2.6 A 4.3 A 7.6 A
Heat
value *
1
11W 16.6W 21W 25W
Control
circuit
Power
supply
voltage
Single-phase 100 to 120 VAC (85 to 132 V) 50/60 Hz
Heat
value *
1
4W 4W 4W 4W
Control method All-digital servo
Inverter method IGBT-driven PWM method
PWM frequency 12.0 kHz 6.0 kHz
Weight Approx. 0.8 kg Approx. 0.8 kg Approx. 1.0 kg Approx. 1.6 kg
Maximum applicable motor capacity 50 W 100 W 200 W 400 W
Applicable
motor
3,000 r/
min type
K05030H K10030L K20030L K40030L
K05030T K10030S K20030S K40030S
2,000-r/
min type

1,000-r/
min type

INC
ABS
ABS
ABS

Omron R88D-KN ML2 Sries Specifications

General

Brand	Omron
Model	R88D-KN ML2 Sries
Category	Servo Drives
Language	English
