3-1
3-1 Servo Drive Specifications
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
3
Specifications
3-1 Servo Drive Specifications
Select the Servo Drive matching the Servomotor to be used. Refer to "Servo Drive and
Servomotor Combination List"(P.2-10).
General Specifications
Note 1.The above items reflect individual evaluation testing. The results may differ under compound conditions.
Note 2.Disconnect all connections to the Servo Drive before attempting a megameter test (insulation resistance
measurement) on a Servo Drive. Failure to follow this guideline may result in damaging the Servo Drive. Never
perform a dielectric strength test on the Servo Drive. Failure to follow this guideline may result in damaging the
internal elements.
Note 3.Depending on the operating conditions, some Servo Drive parts will require maintenance. For details, refer to
"11-5 Periodic Maintenance" (P.11-36).
Item Specifications
Ambient operating
temperature and operating
humidity
0 to 55C, 90% RH max. (with no condensation)
Storage ambient temperature
and humidity
-20 to 65C, 90% RH max. (with no condensation)
Operating and storage
atmosphere
No corrosive gases
Vibration resistance 10 to 60 Hz and at an acceleration of 5.88 m/s
2
or less (Not to be run continuously at
the resonance point)
Impact resistance Acceleration of 19.6 m/s
2
max. 2 times each in X, Y, and Z directions
Insulation resistance Between power supply terminal/power terminal and FG terminal: 0.5 M min. (at 500
VDC Megger)
Dielectric strength Between power supply/power line terminals and FG terminal: 1,500 VAC for 1 min at
50/60 Hz
Protective structure Built into panel
EC
directive
EMC
directive
EN 55011, EN 61000-6-2, IEC 61800-3
Low voltage
command
EN 61800-5-1
Machinery
Directive
EN954-1 (Category 3), EN ISO 13849-1: 2008 (Category 3) (PLc,d), ISO 13849-1:
2006 (Category 3) (PLc,d), EN61508 (SIL2), EN62061 (SIL2), EN61800-5-2 (STO),
IEC61326-3-1 (SIL2)
UL standards UL 508C
CSA standards CSA22.2 No. 14
Korean Radio
Regulations (KC)
Compliant
To Next Page
