3-17
3-1 Servo Drive Specifications
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
3
Specifications
Control Input Details
This is the detailed information about the CN1 Connector input pins.
General-purpose Inputs (IN1 to IN8)
Note:The functions that are allocated by default are given in brackets.
Refer to "Sequence I/O Signal"(P.6-1) for the allocation procedures.
Emergency Stop Input (STOP)
STOP is used when an external sequence such as the host forcibly turns OFF the servo.
If the Immediate Stop Input (STOP) turns ON during the Servomotor rotation, the dynamic brake
makes a deceleration stop. After the motor stops, it remains in servo-free state.
If the Immediate Stop Input (STOP) turns ON when the motor is energized, a Forced alarm input
error (Alarm No. 87.0) will occur.
This input is allocated to the pin 5 with the NC contact in the default setting.
Turn ON the Immediate Stop Input (STOP) at the same time when you turn OFF the main
power. When the main power turns OFF due to an external immediate stop, the motor will
continue to rotate due to residual voltage. This may cause human injuries or damages to the
machine and devices.
Pin 5 : General-purpose Input 1 (IN1) [Emergency Input (STOP)]
Pin 7 : General-purpose Input 2 (IN2) [Forward Drive Prohibition Input (POT)]
Pin 8 : General-purpose Input 3 (IN3) [Reverse Drive Prohibition Input (NOT)]
Pin 9 : General-purpose Input 4 (IN4) [Origin Proximity Input (DEC)]
Pin 10 : General-purpose Input 5 (IN5) [External Latch Input 3 (EXT3)]
Pin 11 : General-purpose Input 6 (IN6) [External Latch Input 2 (EXT2)]
Pin 12 : General-purpose Input 7 (IN7) [External Latch Input 1 (EXT1)]
Pin 13 : General-purpose Input 8 (IN8) [Monitor Input 0 (MON0)]
To Next Page
