3-81
3-6 Reactor Filter Specifications
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
3
Specifications
3-6 Reactor Filter Specifications
Use reactors to suppress harmonic currents. Connect it to a Servo Drive. Select the proper
reactor model according to the Servo Drive to be used.
Specifications
Servo Drive Reactor
Model
Number of
power
phases
Model
Rated
current
Inductance Weight
R88D-KNA5L-ML2
Single-
phase
3G3AX-DL2002 1.6 A 21.4 mH Approx. 0.8 kg
R88D-KN01L-ML2 3G3AX-DL2004 3.2 A 10.7 mH Approx. 1.0 kg
R88D-KN02L-ML2 3G3AX-DL2007 6.1 A 6.75 mH Approx. 1.3 kg
R88D-KN04L-ML2 3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
R88D-KN01H-ML2
Single-
phase
3G3AX-DL2002 1.6 A 21.4 mH Approx. 0.8 kg
3-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KN02H-ML2
Single-
phase
3G3AX-DL2004 3.2 A 10.7 mH Approx. 1.0 kg
3-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KN04H-ML2
Single-
phase
3G3AX-DL2007 6.1 A 6.75 mH Approx. 1.3 kg
3-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KN08H-ML2
Single-
phase
3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
3-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KN10H-ML2
Single-
phase
3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
3-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KN15H-ML2
Single-
phase
3G3AX-DL2022 13.8 A 2.51 mH Approx. 2.1 kg
3-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-KN20H-ML2
3-phase
3G3AX-AL2055 20.0 A 0.88 mH Approx. 4.0 kg
R88D-KN30H-ML2
R88D-KN50H-ML2 3G3AX-AL2110 37.0 A 0.35 mH Approx. 5.0 kg
R88D-KN06F-ML2
3G3AX-AL4025 6.0 A 7.7 mH Approx. 2.7 kgR88D-KN10F-ML2
R88D-KN15F-ML2
R88D-KN20F-ML2
3G3AX-AL4055 10.0 A 3.5 mH Approx. 4.0 kg
R88D-KN30F-ML2
R88D-KN50F-ML2 3G3AX-AL4110 20.0 A 1.3 mH Approx. 6.0 kg
