3-29
3-1 Servo Drive Specifications
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
3
Specifications
USB Connector Specifications (CN7)
Through the USB connection with computer, operations such as parameter setting and
changing, monitoring of control status, checking error status and error history, and parameter
saving and loading can be performed.
Precautions for Correct Use
Use a commercially available USB cable that is shield, equipped with a ferrite core for noise
immunity, and supporting for USB2.0.
The Mini B type USB cable can be used.
Pin
number
Symbol Name Function and interface
1 VBUS
USB signal terminal
Use this function for computer communication.
2D
3D
4 Reserved for manufacturer use Do not connect.
5 GND Signal ground Signal ground
