OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
3
This chapter explains the general specifications, characteristics, connector
specifications and I/O circuits of the Servo Drives, as well as the general
specifications, characteristics, encoder specifications of the Servomotors.
3-1 Servo Drive Specifications ..........................................3-1
3-2 Overload Characteristics (Electronic Thermal Function) ... 3-32
3-3 Servomotor Specifications ........................................3-33
3-4 Cable and Connector Specifications ........................3-58
3-5 External Regeneration Resistor Specifications.......3-79
3-6 Reactor Filter Specifications .....................................3-81
3-7 MECHATROLINK-II Repeater Unit Specifications....3-82
Specifications
