3-73
3-4 Cable and Connector Specifications
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
3
Specifications
Wiring
This is an example to connect a host controller and the Servo Drive by the MECHATROLINK-
II Communications Cable.
Note 1.The cable between the two nodes (L1, L2 ... or Ln) must be 0.5 m or longer.
Note 2.The total length of the cable (L1  L2  ... Ln) must be equal to or shorter than 50 m.
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
NC Unit
L1 L2 Ln
Terminating
Resistor
