4-17
4-2 Wiring
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
4
System Design
Terminal Block Wire Sizes
100-VAC Input Type Wire Sizes: R88D-KNxxL-ML2
*1. Connect OMRON Power Cables to the motor connection terminals.
*2. Use the same wire sizes for B1 and B2.
Model (R88D-)
KNA5L-
ML2
KN01L-
ML2
KN02L-
ML2
KN04L-
ML2
Item
Unit
Power supply capacity
kVA 0.4 0.4 0.5 0.9
Main circuit power
supply input (L1
and L3, or L1, L2
and L3)
Rated current A 1.7 2.6 4.3 7.6
Wire size
 AWG14 to 18
Control circuit
power supply input
(L1C and L2C)
Wire size

AWG18
Motor connection
terminals (U, V, W,
and FG)
*1*2
Rated current A 1.2 1.7 2.5 4.6
Wire size

AWG14 to 18
Frame ground (FG) Wire size

AWG14
Screw size

M4
Tightening torque N•m 1.2
