4-3 Wiring Conforming to EMC Directives
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
4
System Design
Noise Filter for Power Supply Input
We recommend you to use the noise filter for the Servo Drive.
Drive
Noise filter for power supply input
Phase
Model Model
Rated
current
Leakage current
(60 Hz) max
Manufacturer
Single-
phase
R88D-KA5L
SUP-EK5-ER-6 5 A
1.0 mA
(at 250 VAC)
Okaya
Electric
Industries
Co., Ltd.
R88D-K01L
R88D-K02L
Single-
phase
R88D-K04L 3SUP-HU10-ER-6 10 A
3.5 mA
(at 500 VAC)
Single-
phase
R88D-K01H
SUP-EK5-ER-6 5 A
1.0 mA
(at 250 VAC)
3-phase
3SUP-HU10-ER-6 10 A
3.5 mA
(at 500 VAC)
Single-
phase
R88D-K02H
SUP-EK5-ER-6 5 A
1.0 mA
(at 250 VAC)
3-phase
3SUP-HU10-ER-6 10 A
3.5 mA
(at 500 VAC)
Single-
phase
R88D-K04H
SUP-EK5-ER-6 5 A
1.0 mA
(at 250 VAC)
3-phase
3SUP-HU10-ER-6 10 A
3.5 mA
(at 500 VAC)
Single or
3-phase
R88D-K08H
R88D-K10H
3SUP-HU30-ER-6 30 A
3.5 mA
(at 500 VAC)
R88D-K15H
3-phase
R88D-K20H 3SUP-HU50-ER-6 50 A
3.5 mA
(at 500 VAC)
R88D-K30H
3SUP-HL50-ER-6B 50 A
8.0 mA
(at 500 VAC)
R88D-K50H
R88D-K06F
FN258L-16-07 16 A
0.8 mA
(at 440 VAC/50 Hz)
Schaffner
EMC Inc.
R88D-K10F
R88D-K15F
R88D-K20F
R88D-K30F
FN258L-30-07 30 A
0.8 mA
(at 440 VAC/50 Hz)
R88D-K50F
