4-44
4-3 Wiring Conforming to EMC Directives
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
4
System Design
3G3AX-NFO03/-NFO04/-NFO05/-NFO06
C
B
A
P
F
E
6
−
O
2
−
N
50 30
4
−φ
6.5
50
H
J
Model
Dimensions (mm)
A B C E F H J N O P
3G3AX-NFO03 160 145 130 80 112 120 

M4 154
3G3AX-NFO04 200 180 160 100 162 150 120 M5 M5 210
3G3AX-NFO05 220 200 180 100 182 170 140 M6 M6 230
3G3AX-NFO06 220 200 180 100 182 170 140 M8 M8 237
