11-10
11-3 Alarms
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
11
Error and Maintenance
50
0
External encoder
connection error
An error was detected in external
encoder connection.


1
External encoder
communications data error
An error was detected in external
encoder communications data.


51
0
External encoder status
error 0
An external encoder error code was
detected.


1
External encoder status
error 1


2
External encoder status
error 2


3
External encoder status
error 3


4
External encoder status
error 4


5
External encoder status
error 5


55
0
Phase-A connection error An error was detected in the external
encoder phase A connection.

1
Phase-B connection error An error was detected in the external
encoder phase B connection.

2
Phase-Z connection error An error was detected in the external
encoder phase Z connection.

82 0
Node address setting error The node address set by the rotary
switches on the Drive exceeded the
setting range, when the control power
was turned on.

83 0
Communications error Failures to correctly receive the data
to receive during the
MECHATROLINK-II communication
cycles continued in series more often
than the value set on the
Communications Control (Pn800).

84
0
Transmission cycle error Failed to receive synchronization
frames (SYNC) according to
transmission cycle while the
MECHATROLINK-II communication
connection is being established.

3
Synchronization error An error occurred while
synchronization is established.

4
SYNC_SET error
In the asynchronous MECHATROLINK-
II communications state, a
communication error occurs while
SYNC_SET command is executed.

86 0
Watchdog data error An error occurred in the
synchronization data that is
exchanged between Master and Slave
nodes for every MECHATROLINK-II
communications cycle.

87 0
Forced alarm input error The forced alarm input signal was
input.

Alarm
number
Error detection function
Detection details and
probable cause
Attribute
Main Sub History
Can be
reset
Emergency
stop *1
