Omron R88D-KN ML2 Sries User Manual

2-13
2-3 Standard Model List
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
2
Standard Models and External Dimensions
Motor Power Cables (Flexible Cables)
Note.There are separate connectors for power and brakes for 100 V and 200 V 3,000-r/min motors of 50
to 750 W. Therefore, when a motor with a brake is used, it requires both a power cable for a motor
without a brake and a brake cable.
Specifications
Model
For motor without
brake
For motor with brake
[100 V and 200 V]
For 3,000-r/min motors of 50 to 750 W
1.5 m R88A-CAKA001-5SR-E

3 m R88A-CAKA003SR-E

5 m R88A-CAKA005SR-E

10 m R88A-CAKA010SR-E

15 m R88A-CAKA015SR-E

20 m R88A-CAKA020SR-E

[200 V]
For 3,000-r/min motors of 1 to 2 kW
For 2,000-r/min motors of 1 to 2 kW
For 1,000-r/min motors of 900 W
1.5 m
R88A-CAGB001-5SR-E R88A-CAGB001-5BR-E
3 m R88A-CAGB003SR-E R88A-CAGB003BR-E
5 m R88A-CAGB005SR-E R88A-CAGB005BR-E
10 m R88A-CAGB010SR-E R88A-CAGB010BR-E
15 m R88A-CAGB015SR-E R88A-CAGB015BR-E
20 m R88A-CAGB020SR-E R88A-CAGB020BR-E
[400 V]
For 3,000-r/min motors of 750 W to 2 kW
For 2,000-r/min motors of 400 W to 2 kW
For 1,000-r/min motors of 900 W
1.5 m
R88A-CAGB001-5SR-E R88A-CAKF001-5BR-E
3 m R88A-CAGB003SR-E R88A-CAKF003BR-E
5 m R88A-CAGB005SR-E R88A-CAKF005BR-E
10 m R88A-CAGB010SR-E R88A-CAKF010BR-E
15 m R88A-CAGB015SR-E R88A-CAKF015BR-E
20 m R88A-CAGB020SR-E R88A-CAKF020BR-E
For 3,000-r/min motors of 3 to 5 kW
For 2,000-r/min motors of 3 to 5 kW
For 1,000-r/min motors of 2 to 3 kW
1.5 m
R88A-CAGD001-5SR-E R88A-CAGD001-5BR-E
3 m R88A-CAGD003SR-E R88A-CAGD003BR-E
5 m R88A-CAGD005SR-E R88A-CAGD005BR-E
10 m R88A-CAGD010SR-E R88A-CAGD010BR-E
15 m R88A-CAGD015SR-E R88A-CAGD015BR-E
20 m R88A-CAGD020SR-E R88A-CAGD020BR-E
